The current is settable to 250mA, 300mA or 350mA. Please select from above.
If you do not require this extra service & wish to purchase this product at the pre-configured current of 200mA please click here.
Features and Benefits
- Unique small size driver enabling hidden lighting with miniaturized downlights, pendants, spotlights and wall washers
- Independent driver that fits through 35mm aperture with 100mm plenum ceiling.
- Control: Phase dimming.
- Natural and flicker-safe dimming: Dim with smooth brightness changes, excellent flicker performance.
- Regional standards: designed to meet the standards in Europe (ENEC), Australia and New Zealand (RCM).
- Performance: smallest driver with wide operating window, including COB operating point (36V / 350mA). Constant current SELV output to LEDs. Drivers are pre-wired to the LEDs.
- European mains input (220-240VAC), low inrush current and Total Harmonic Distortion. Can be used up to 45°C (Phase dimming products) ambient temperature. Supports central battery (DC) emergency
Input Characteristics
Nominal input voltage range AC: 220 - 240V (ENEC)
Maximum input current: 80mA
Output Characteristics
Maximum LED output power: 14W
Number of LED outputs: 1
Settable LED output current range: 200mA, 250mA, 300mA or 350mA.
LED output voltage range: 20 - 40V
